    Project-wide update or retag

    Resequences or updates component tags, wire numbers, cross references, signal references, select drawing properties, ladders, and title blocks.

    ac.mouse.gif Ribbon: Project tab ac.menuaro.gif Project Tools panel ac.menuaro.gif Update/Retag.icon_cmd_ace_bump.png

    ac.mouse.gif Toolbar: Projecticon_cmd_ace_bump.png

    ac.mouse.gif Menu: Projects ac.menuaro.gif Project-Wide Update/Retag

    ac.keyboard.gif Command entry: AEPROJUPDATE

    In one command, modify drawing properties and sheet values, renumber ladders, retag components, redo cross referencing, and update title blocks.


    Component Retag

    Retag all nonfixed components.

    Note: If Ladder References Resequence is selected, the component retag process is performed after the ladder resequencing is complete.

    Component Cross-reference Update

    Updates the cross-referencing for components on selected drawings.

    Note: Cross-references are updated after other options such as component retag or ladder resequencing are performed.

    Wire Number and Signal Tag/Retag

    Sets options for wire number retagging.

    Click Setup to display the Wire Tagging (project-wide) dialog box. Here you can insert or update wire numbers associated with wire line networks across a project

    Ladder References

    Renumbers each ladder sequentially.

    Resequence Setup

    Defines options for starting reference numbers and how to sequence ladders from drawing to drawing.

    Renumber Ladders dialog box

    Renumbers the ladder for the selected drawings from the active project.

    1. Enter the ladder reference number for the first drawing.

    2. For all subsequent drawings:

      • Select to use the next sequential reference.

      • Select Skip, drawing to drawing count to enter an amount to skip for the first ladder reference of the next drawing.

    Bump Up or Down

    Moves ladder references up if drawings were added to the middle of a project or moves ladder references down if drawings were removed from the project.

    Note: Enter a negative number to move ladder references down.

    Sheet (%S value)

    Automates resequencing the sheet value on consecutive drawings.

    Resequence - Start with

    Enter a number to start the resequencing.

    Bump-Up/Down by

    Select to move the current sheet value up or down by a given count.

    Drawing (%D value)

    Performs a project-wide update of the %D "DWG NAME" parameter of the drawing.

    Other Configuration Settings

    Updates the drawing parameters related to component, cross-reference, and wire tagging modes and format project-wide.

    Title Block Update

    Automates updating title block information for the active drawing or the entire project drawing set.
