Complete the Assembly

Repeat the previous procedure to create the rest of the assembly. The table contains a list of file names with the surfaces, sketches, and work planes to use with the Derive command.

1. Repeat the procedure to create the five frame parts according to the following table. Be sure to turn off the visibility of derived surfaces after creating the extrusion.

   File Name	Surfaces	Sketch	Work Geometry
   Frame2	Srf1 and Srf2	Sketch3	Work Plane6
   Frame3	Srf2 and Srf3	Sketch4	Work Plane1
   Frame4	Srf3 and Srf4	Sketch5	Work Plane2
   Frame5	Srf4 and Srf5	Sketch6	Work Plane3
   Frame6	Srf5 and Srf6	Sketch7	Work Plane4



2. When all part files are complete, save Frame.iam and all dependents.
