Next, you change the appearance of the arbor press frame.
- Select the Arbor_Frame component in the graphics window or browser, and then select Aluminum (Cast) from the Appearance Override pulldown list. The list is located at the top of the Autodesk Inventor LT window in the Quick Access Toolbar and shows the current appearance selection.
- Click Render Image.
- Select 320 x 240 from the Resolution menu.
- Select the Output tab, and then change the Antialiasing to Low Antialiasing.
- Click Render.
